Network Monitoring

Overview
Data collected

Measure SDK can capture network requests, responses and failures along with useful metrics to help understand how APIs are performing in production from an end user perspective.

Overview#

Most heavy lifting of network monitoring is done automatically by the Measure SDK. There are a lot of configuration options available to control the behavior of network monitoring.

Android

On Android, network requests made using the OkHttp library, including any third party libraries, are automatically tracked by simply adding the Measure Android Gradle Plugin.

iOS

On iOS, network requests made using the URLSession, including any third party libraries, are automatically tracked by simply adding the iOS SDK to your project.

Flutter

On Flutter, network requests made using the Dio package can be tracked by adding the measure_dio package to your project. This package provides MsrInterceptor that can automatically track network requests done using Dio.

dependencies:
  measure_dio: ^0.3.0

final dio = Dio();
dio.interceptors.add(MsrInterceptor());

For any other HTTP client libraries, you can manually track network requests using the trackHttpEvent method. Example using http package:

import 'package:http/http.dart' as http;
import 'package:measure/measure.dart';

Future<http.Response> trackedGet(Uri uri, {Map<String, String>? headers}) async {
  return _trackRequest(() => http.get(uri, headers: headers), uri, 'get', headers);
}

Future<http.Response> trackedPost(Uri uri, {Map<String, String>? headers, Object? body}) async {
  return _trackRequest(() => http.post(uri, headers: headers, body: body), uri, 'post', headers, body);
}

Future<http.Response> _trackRequest(
    Future<http.Response> Function() request,
    Uri uri,
    String method,
    Map<String, String>? headers,
    [Object? body]
    ) async {
  final measure = Measure.instance;
  final startTime = measure.getTimestamp();

  try {
    final response = await request();

    measure.trackHttpEvent(
      url: uri.toString(),
      method: method,
      statusCode: response.statusCode,
      startTime: startTime,
      endTime: measure.getTimestamp(),
      requestHeaders: headers,
      responseHeaders: response.headers,
      requestBody: body?.toString(),
      responseBody: response.body,
      client: 'http',
    );

    return response;
  } catch (e) {
    measure.trackHttpEvent(
      url: uri.toString(),
      method: method,
      startTime: startTime,
      endTime: measure.getTimestamp(),
      failureReason: e.runtimeType.toString(),
      failureDescription: e.toString(),
      requestHeaders: headers,
      requestBody: body?.toString(),
      client: 'http',
    );
    rethrow;
  }
}

Configuration Options#

By default, all network requests are tracked with key information like the URL, HTTP method, response status code, timestamp, any failure reason, and the duration of the request. You can also optionally, disable certain URLs from being tracked or track additional information like request and response headers, request body, and response body.

All configuration options can be set during SDK initialization.

Configure URLs to track or ignore#

Use httpUrlAllowlist to specify a list of URLs that should be tracked. If this is set, only the URLs in this list will be tracked. This is useful to ensure that only specific APIs are monitored, especially in cases where you want to avoid tracking sensitive or unnecessary URLs.

If you are unsure about which URLs to track, you can leave this option empty and instead use httpUrlBlocklist to specify a list of URLs that should not be tracked.

You should only use one of these options at a time, either httpUrlAllowlist or httpUrlBlocklist. If both are specified, the SDK will take httpUrlAllowlist as the source of truth and ignore the httpUrlBlocklist.

The check for URLs is done using a simple string match. For example, if you specify https://api.example.com/, then all requests to https://api.example.com/ and its sub-paths will be tracked. If you want to track only a specific endpoint, you can specify the full URL, like https://api.example.com/v1/users.

Note that wildcards are not supported yet.

Track HTTP headers#

Use trackHttpHeaders to control whether HTTP headers should be tracked for network requests. By default, this is set to false.

To track headers, set trackHttpHeaders to true. This applies to both automatically captured network requests and manually tracked requests via trackHttpEvent.

By default, the following headers are always disallowed to prevent sensitive information from leaking:

Authorization
Cookie
Set-Cookie
Proxy-Authorization
WWW-Authenticate
X-Api-Key

To add additional headers to this list, use the httpHeadersBlocklist configuration option to provide a list of additional headers that should not be tracked.

Track HTTP body#

Use trackHttpBody to control whether HTTP request and response bodies should be tracked for network requests. By default, this is set to false. This option only works for application/json content type.

On iOS, enable network tracking for a given URLSession to track HTTP body. This is done by adding the MsrNetworkInterceptor to the URLSession configuration as shown below:

let configuration = URLSessionConfiguration.default
MsrNetworkInterceptor.enable(on: configuration)
self.session = URLSession(configuration: configuration)

[!CAUTION] Note that tracking HTTP bodies can significantly increase the size of the collected data, so it should be used with caution. Typically, setting this to true is only recommended using a feature flag which can be controlled remotely and turned on for very specific conditions for a limited time.

Data collected#

Checkout the data collected by Measure for each HTTP request in the HTTP Event section.
